Airport Express Base Station
Roll over image to zoom in Click on image to zoom
Airport Express Base Station

Airport Express Base Station

AppleSKU: MC414ZP/A
Price:
₱4,990.00
Stock:
Sold out

Pickup currently unavailable at Switch Glorietta 2



Size and Weight

  • 98 mm
  • 23 mm
  • Status Light
  • Power
  • Ethernet
    WAN Port
  • Ethernet
    LAN Port
  • USB Port
  • Analog/Optical
    Audio Jack

  • Dimensions: 98 mm (3.85 inches) by 98 mm (3.85 inches) by 23 mm (0.9 inch)

  • Weight: 240 grams (8.5 ounces)1

Wireless

  • IEEE 802.11a/b/g/n

  • Simultaneous dual-band 2.4GHz and 5GHz

  • Radio output power: 20.5 dBm maximum (varies by country)

  • Channels 1-11, 36-116, and 132-165 approved for use in the United States and Canada

  • Channels 1-13, 36-64, and 100-140 approved for use in Europe and Japan

  • Channels 1-13, 36-64, and 149-165 approved for use in Australia, Hong Kong, and New Zealand

Compatibility

  • Interoperable with 802.11a, 802.11b, 802.11g, and 802.11n-enabled Mac computers, iOS devices, Apple TV, Windows-based PCs, and other Wi‑Fi devices

  • NAT, DHCP, PPPoE, VPN Passthrough (IPSec, PPTP, and L2TP), DNS Proxy, SNMP, IPv6 (6to4 and manual tunnels)

Security

  • Wi‑Fi Protected Access™ (WPA/WPA2)2

  • WPA/WPA2 Enterprise2

  • Wireless security (WEP) configurable for 40-bit and 128-bit encryption

  • MAC address filtering

  • NAT firewall

  • 802.1X, PEAP, LEAP, TTLS, TLS, FAST

  • Time-based access control

Software and Documentation

Interfaces

  • Simultaneous dual-band 802.11n wireless

  • 10/100BASE-T Ethernet WAN port for connecting a DSL modem, cable modem, or Ethernet network

  • 10/100BASE-T Ethernet LAN port for connecting a computer, Ethernet hub, or networked printer

  • USB 2 port for connecting a USB printer

  • 3.5-mm audio minijack for analog or optical digital sound3

Number of Users

  • 50

Electrical and Environmental Requirements

  • 100–240V AC, 50–60Hz; input current: 0.2 amp

  • Operating temperature: 0° to 35° C (32° to 95° F)

  • Storage temperature: -25° to 60° C (-13° to 140° F)

  • Relative humidity (operating): 20% to 90% non-condensing

  • Operating altitude: tested up to 3000 m (10,000 feet)

  • Maximum storage altitude: 4500 m (15,000 feet)

Agency Approval

  • FCC 15 Class B, Canada RSS-210, EN 300-328, EN 301-489, EN 301 893, ARIB STD-T66, RCR STD-T33, AS/NZS 4268: 2003, UL 60950, CSA-C22.2 No. 60950

System Requirements

Setup and Administration

Wireless Device Access

Any Wi‑Fi-enabled device that uses the 802.11a/b/g/n specification

Shared Printing with a USB Printer

  • USB printer

  • Mac with OS X v10.2.7 or later

  • PC with Windows XP (SP3), Windows Vista (SP2), Windows 7 (SP1), or Windows 8
